Fully Electric Pallet Truck
The Fully Electric Pallet Truck is designed for effortless pallet transportation with powered lifting and powered travel. It delivers high productivity, reduced operator fatigue, and smooth material handling, making it ideal for busy warehouses and industrial facilities.
Features
- Fully powered lifting and travel functions
- High-performance rechargeable battery
- Compact design for efficient maneuvering
- Smooth acceleration and precise control
- Heavy-duty drive system for reliable performance
- Ergonomic controls for operator comfort
- Ideal for continuous and high-volume material handling
| FULLY ELECTRIC PALLET TRUCK | DETAILS |
|---|---|
| Model | HT-EPT-20 |
| Load Capacity | 2000 kg (2 Ton) |
| Load Center | 600 mm |
| Power Type | Fully Electric |
| Fork Size (L × W) | 1150 × 550 mm |
| Optional Fork Width | 685 mm |
| Fork Length | 1150 mm |
| Lowered Fork Height | 85 mm |
| Maximum Lift Height | 200 mm |
| Overall Fork Width | 550 mm / 685 mm |
| Drive Motor | 0.75 kW AC |
| Lift Motor | 0.8 kW DC |
| Travel Speed (Loaded / Unloaded) | 4.5 / 5.0 km/h |
| Lifting Speed (Loaded / Unloaded) | 20 / 25 mm/s |
| Lowering Speed (Loaded / Unloaded) | Adjustable |
| Gradeability (Loaded) | 5% |
| Turning Radius | 1360 mm |
| Drive Wheel | Polyurethane (PU) |
| Load Rollers | Tandem PU |
| Battery Type | Lithium-Ion |
| Battery Voltage / Capacity | 48V / 20Ah |
| Battery Weight | Approx. 8 kg |
| Battery Charging Time | 2–3 Hours |
| Battery Working Time | Up to 5–6 Hours |
| Charger Input | 220V AC |
| Brake System | Electromagnetic Brake |
| Steering | Electric Power Steering (Optional) |
| Controller | Curtis / ZAPI (or Equivalent) |
| Display | LCD Digital Display |
| Net Weight | Approx. 145–160 kg |
×
